HDP1100 Roll-to-Dynamic-Folding-to-Saddle-Stitching Digital Line

Equipment Introduction

The HDP1100 Roll-to-Dynamic-Folding-to-Saddle-Stitching Digital Line is a fully automated solution that converts digitally printed rolls directly into finished saddle-stitched booklets with variable page counts. The HDP UW1100 Unwinder provides stable web feeding, followed by longitudinal creasing and pre-perforation in the HDP SPF1100 Single Plowfolder. Barcode data controls the HDP CD520 Dynamic Cutter for variable-length cross-cutting and automatic waste rejection, while the HDP DFU660 Dynamic Folder changes folding sequences without stopping production to produce 8-, 12-, 16- or 24-page signatures and automatically handle tail sections. The folded signatures are transferred through a telescopic conveyor to the HDP200 Digital Collating Feeder for sequential gathering and barcode-controlled cover matching, before entering the HDP SS4500 Digital Saddle Stitcher for cover inserting, wire stitching and inline three-side trimming. By reducing the number of individual sheets handled during collating, the synchronized workflow improves production efficiency and enables flexible Book-of-One and short-run booklet manufacturing from roll to finished product.

Technical Specifications

  • Max. Unwinding Width
  • 1,100 mm
  • Max. Unwinding Diameter
  • 1,300 mm
  • Max. Cutting Width
  • 520 mm
  • Paper Weight
  • 60–157 gsm
  • Variable Folding Formats
  • 8/12/16/24 pages
  • Max. Cover Size (W × L)
  • 470 × 350 mm
  • Min. Cover Size (W × L)
  • 210 × 150 mm
  • Max. Booklet Size Before Trimming (W × L)
  • 235 × 350 mm
  • Min. Booklet Size Before Trimming (W × L)
  • 105 × 150 mm
  • Max. Stitching Thickness
  • 5 mm
  • Equivalent Max. Finished Booklet Thickness
  • 10 mm
  • Stitching Distance
  • 60–150 mm
  • Mechanical Speed
  • 2,900–4,500 booklets/hour
  • Rated Production Reference
  • 64 pages per booklet
  • Changeover Time
  • 15 minutes
  • Cover Feeder
  • 1 integrated cover feeder
  • Cover-to-Content Barcode Matching
  • Yes
  • Signature Gathering Device
  • Yes
  • Power Supply
  • 380 V AC
  • Installed Power
  • 64 kW
  • Compressed Air
  • 6 bar, 2 L/min
  • Working Temperature
  • 5–40 °C
  • Working Humidity
  • 15%–85%
  • Dimensions (L × W × H)
  • 20,000 × 5,500 × 1,500 mm
  • Machine Weight
  • 3,000 kg

Dimensions & Layout

Component Equipment

HDP UW1100 Unwinder
HDP SPF1100 Single Plowfolder
HDP CD520 Dynamic Cutter
HDP DFU660 Dynamic Folder
HDP200 Digital Collating Feeder
HDP SS4500 Digital Saddle Stitcher
