HDP1100 Roll to Dynamic Folding to Sewing Digital Line

Equipment Introduction

The HDP1100 Roll to Dynamic Folding to Sewing Digital Line is a fully automated inline solution designed for efficient, variable-data and “Book-of-One” sewn book block production. The HDP UW1100 Unwinder provides stable continuous-web feeding to the HDP SPF1100 Single Plowfolder, where the printed web undergoes precise longitudinal creasing and pre-perforation. The HDP CD520 Dynamic Cutter then reads barcode data to perform variable-length cross-cutting and automatically reject setup waste without interrupting production. Cut sheets are transferred directly to the HDP DFU660 Dynamic Folder, which changes folding sequences on the fly to produce signatures with different page counts and manage tail signatures without manual adjustment. The folded signatures are conveyed through a Telescopic Conveyor to the HDP200 Digital Collating Feeder, where they are accurately collated in sequence and continuously delivered to the HDP SEW Digital Sewing Machine for thread sewing. By forming multi-page signatures before collating, the line reduces the number of feeding cycles required compared with conventional sheet-by-sheet workflows, improving collating efficiency and supporting stable, continuous sewing production. The completed sewn book blocks can vary in page count and thickness and are ready for subsequent perfect binding or hardcover binding processes.

Tech specifications

  • Max Unwinding Width
  • 1100 mm
  • Max Unwinding Diameter
  • 1300 mm
  • Max Cutting Width
  • 520 mm
  • Variable Folding
  • 8, 12, 16, 24, 32 pp
  • Max Signature Size
  • 420 × 320 mm
  • Min Signature Size
  • 120 × 75 mm
  • Paper Weight
  • 60–157 gsm
  • Max Mechanical Speed
  • 12000 cycles/h (500 A4 sheets/min)
  • Machine Weight
  • 10000 kg
  • Changeover Time
  • 5 min
  • Dimensions
  • 18000 × 2300 × 1500 mm (L × W × H)
  • Power
  • 42 kW
  • Power Supply
  • 380 V AC
  • Compressed Air
  • 6 bar, 2 L/min
  • Working Humidity
  • 15%–85%
  • Working Temperature
  • 5–40 ℃
  • Signature Gathering Device
  • YES
  • Cover and Inner Pages Barcode Matching
  • YES

Dimensions & Layout

Component Equipment

READY TO FIND
THE RIGHT MACHINE?

Please provide your contact details and message.
Our sales experts will reach out to you shortly.

EXPLORE MORE SOLUTIONS

READY TO FIND
THE RIGHT MACHINE?

Please provide your contact details and message.
Our sales experts will reach out to you shortly.

FREQUENTLY ASKED QUESTIONS

Q: What is HDP?
A: HDP is a specialized digital finishing brand under HXCP Machinery, focused on complete post-press solutions for digitally printed rolls. We help convert printed paper rolls into finished books through cutting, folding, sewing, perfect binding, saddle stitching, hardcover binding, lay-flat binding, and other bookbinding processes. HDP is designed to support true print-on-demand production from one book upward.
Q: What is your warranty policy?
A: We provide a standard 12-month warranty from the date of installation. During the warranty period, we offer free replacement parts for manufacturing defects and provide lifelong online technical support.
Q: What are HDP’s competitive advantages?
A: HDP is one of China’s leading manufacturers dedicated to digital finishing technology. Since 2024, we have developed and delivered advanced digital finishing systems to customers worldwide. With self-developed patented technologies such as dynamic folding, HDP helps traditional bookbinding companies enter digital finishing with lower investment and higher flexibility. We are also one of the few manufacturers able to provide a full range of digital binding solutions, including perfect binding, saddle stitching, thread sewing, lay-flat binding, and hardcover binding.
Q: Where is HDP located?
A: HDP is backed by HXCP Machinery, with its headquarters and manufacturing facilities located in Dongguan, Guangdong, China. In the United States, HDP operates through HDP Americas Inc. in Upland, California. Located in Southern California within the Greater Los Angeles area, the 400-square-meter facility serves as a regional showroom, technical service center and spare parts hub supporting customers throughout the Americas. Customers are warmly welcome to visit HDP in either China or the United States.
Q: How can I contact HDP?
A: You can contact us via WhatsApp at +86 186 1055 1470, email us at HXCPCHINA@gmail.com, or submit an inquiry directly through our website. Our sales team will respond promptly.
Q: What is the relationship between HDP, HXCP, and ChinaPrintech?
A: HXCP Machinery is the group company, founded in 1993, and is one of China's leading manufacturers and solution providers in post-press bookbinding equipment. ChinaPrintech, established in 2020, serves as the group's global export and marketing platform, offering one-stop bookbinding equipment solutions. HDP, established in 2024, is a specialized sub-brand focused on the development, manufacturing, and sales of digital finishing equipment and solutions. Both HDP and ChinaPrintech are brands under HXCP Machinery.
Q: What products and solutions does HDP offer?
A: HDP provides complete digital finishing equipment and integrated solutions for roll-fed digital printing applications. Our equipment includes unwinders, plow folders, dynamic cutters, dynamic folders, digital sewing systems, digital book block preparation lines, digital casing-in machines, and related automation modules. Our solutions include roll-to-book-block, roll-to-perfect-binding, roll-to-saddle-stitching, roll-to-hardcover-binding, and other customized digital book production lines.
Q: What payment methods do you accept?
A: We mainly accept T/T and L/C at sight. For most orders, the standard payment term is a deposit by T/T, with the balance paid before shipment. Specific payment terms can be confirmed based on the order details and project requirements.
Q: What is the difference between purchasing through a local agent and buying directly from HDP?
A: Whether you purchase through an authorized local agent or directly from HDP, you will receive competitive and consistent pricing, as well as standardized service support. However, we generally recommend purchasing through our certified local agents when available, as they can provide faster communication in your local language and time zone, easier access to spare parts, and more efficient on-site service. HDP-certified agents are reviewed regularly to ensure reliable and continuous local support.
